Solo10G PCIe Card

10GBASE-T 10 Gigabit Ethernet PCI Express 3.0 Adapter Card with NBASE-T Ethernet Support


Blazing-Fast 10GBASE-T Connectivity, Cool Price

With recent advances in technology, plus increasingly affordable gear, the transition to capturing and outputting content at 4K and higher resolutions has happened fast—the need for faster than Gigabit Ethernet speeds to transfer all that data has accelerated equally fast. For post-production shared storage workgroups and other bandwidth-intensive workflows, 10Gb Ethernet is the new data transfer standard. Speeding its adoption, very affordable 10Gb Ethernet switches with RJ45 (copper) have significantly reduced the cost of setting up 10GbE infrastructure, but the price of adding client connectivity has remained a barrier for some. Now, there is an equally affordable 10Gb Ethernet interface for your desktop and workstation computers—Sonnet’s Solo10G™ PCIe Card, a powerfully simple solution for adding blazing-fast 10GBASE-T 10GbE network connectivity to Mac®, Windows®, and Linux® computers at a price that’s sure to please.

Key Features:

  • Adds 10GBASE-T 10GbE Connectivity—Adds an RJ45 10 Gigabit Ethernet port to your computer with PCIe slots
  • Cost-Effective—Low-cost PCIe card connects to 10GbE infrastructure via inexpensive CAT 6 or CAT 6A cables at distances up to 55 or 100 meters, respectively
  • Features NBASE-T Technology—5 Gb/s and 2.5 Gb/s speeds supported over existing CAT 5e (or better) cabling at distances up to 100 meters(1)
  • Supports AVB(2)—Audio Video Bridging (IEEE 802.1Qav, AVB)
  • Optimized for Thunderbolt—Ideal for use in Sonnet’s Echo™ Express and xMac™ Thunderbolt-to-PCIe card expansion systems
  • Easy Setup—Configure using your computer’s operating system network device configuration tools


Technical Specifications


Mac Compatibility
  • Mac Pro® 5,1 or 7,1 (2019)
  • macOS® 10.13.6+
  • macOS Ventura compatible
  • AVB (Audio Video Bridging, IEEE 802.1Qav)(2)
PC or Server Compatibility
  • Windows® 11, 10; Server 2022, 2019
  • Linux Kernel 5x
  • VMware ESXi 8,7

Hardware
Part Number G10E-1X-E3
Form Factor Low-profile PCIe computer card
External Connectors One RJ45 port
Bus Interface PCI Express v3.0, x4
10GbE Controller Marvell AQC107S
Network Support
  • 10GBASE-T
  • 100 meters using CAT6A cabling
  • 55 meters using CAT6 cabling


  • 5GBASE-T, 2.5GBASE-T, 1000BASE-T,
  • 100BASE-TX
  • 100 meters using CAT 5e (or better) cabling(1)

Packets Maximum packet size: 16352 bytes (jumbo frames) 9000 bytes under macOS
Data Rate Supported per Port 10 Gb/s, 5 Gb/s, 2.5 Gb/s, 1 Gb/s, 100 Mb/s
Advanced Features
  • Flow control support
  • MSI (Message Signaled Interrupts)
  • RSS (Receive-Side Scaling)
  • Interrupt coalescing
  • Multicast filtering
  • Energy-Efficient Ethernet (IEEE 802.3az)
  • 64-bit address support for systems using more than 4GB of physical memory
  • Wake-on-LAN supported

Stateless Offloads
  • TCP, UDP and IPv4 checksum offloading
  • TSO (TCP Segmentation Offload, AKA Large Send Offload)
  • LRO (Large Receive Offload)
  • RSS (Receiver Side Scaling)

Compliance
  • RoHS 3 (Directive 2015/863)
  • IEC62368-1 and IEC62368-2

Package Contents
  • Solo10G PCIe Card
  • Two mounting brackets (full-height and low-profile)
  • Documentation

Warranty 1 Year
